Dayton Audio SIG150-4 standard | Fs 63 Hz, 90.7 dB, Qts 0.467 | LoudspeakerLab

Thiele-Small parameters

Fs: 63 Hz; Qts: 0.467; Qes: 0.507; Qms: 5.812; Vas: 7.73 L; Sd: 96.8 cm²; Re: 3.68 Ω; Le: 0.36 mH; Sensitivity: 90.7 dB; Nominal Z: 4.0 Ω; Measured range: 20-20000 Hz

Driver quality scores

On-axis flatness 59 · DI tracking 63 · DI smoothness 39

Usable passband

Scored passband 95 Hz–3.7 kHz

Measurement coverage

Spec-sheet profiles · Off-axis H/V response data available.

Recommended enclosure

Vented ~8.7 L · Fb 61 Hz

Measurement profiles

• spec sheet (spec_sheet)

Where to buy

• blackdotaudio — $193.29 PLN
• parts_express — $42.98 USD
• solen — $64.74 CAD
• soundimports — $37.15 EUR

Measurement quality

LoudspeakerLab evidence grade: C+ (57.0/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.
