Dayton Audio RSS265HO-44 standard | Fs 28 Hz, 78.6 dB, Qts 0.450 | LoudspeakerLab

Thiele-Small parameters

Fs: 28 Hz; Qts: 0.450; Qes: 0.500; Qms: 4.420; Vas: 34.80 L; Sd: 352.3 cm²; Re: 1.60 Ω; Le: 0.77 mH; Sensitivity: 78.6 dB; Nominal Z: 2.1 Ω; Measured range: 20-20000 Hz

Driver quality scores

On-axis flatness 69

Usable passband

Scored passband 41 Hz–2.3 kHz

Measurement coverage

Spec-sheet profiles

Recommended enclosure

Vented ~36.2 L · Fb 28 Hz

Measurement profiles

• spec sheet (spec_sheet)

Where to buy

• blackdotaudio — $1504.79 PLN
• parts_express — $188.78 USD
• soundimports — $289.21 EUR
• theloudspeakerkit — $549.00 AUD

Measurement quality

LoudspeakerLab evidence grade: C (46.8/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.
