Dayton Audio RS75T-8 standard | Fs 189 Hz, 81.4 dB, Qts 0.946 | LoudspeakerLab

Thiele-Small parameters

Fs: 189 Hz; Qts: 0.946; Qes: 1.129; Qms: 5.837; Vas: 0.22 L; Sd: 15.2 cm²; Re: 6.11 Ω; Le: 0.32 mH; Sensitivity: 81.4 dB; Nominal Z: 6.4 Ω; Measured range: 20-19346 Hz

Driver quality scores

On-axis flatness 62 · DI tracking 51 · DI smoothness 6

Usable passband

Scored passband 286 Hz–7.8 kHz

Measurement coverage

Spec-sheet profiles · Off-axis H/V response data available.

Recommended enclosure

Sealed ~0.5 L

Measurement profiles

• spec sheet (spec_sheet)

Where to buy

• parts_express — $25.58 USD
• rumoh — $41.90 EUR
• solen — $52.64 CAD
• soundimports — $38.39 EUR
• theloudspeakerkit — $79.50 AUD

Measurement quality

LoudspeakerLab evidence grade: C+ (56.8/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.
