Dayton PCS12-4 standard | Fs 30 Hz, 90.6 dB, Qts 0.670 | LoudspeakerLab

Dayton PCS12-4 standard measurements on LoudspeakerLab. 90.6 dB sensitivity. Fs 30 Hz. Qts 0.670. Evidence grade A- (80.0/100).

Thiele-Small parameters

Fs: 30 Hz; Qts: 0.670; Qes: 0.750; Qms: 6.400; Vas: 88.90 L; Sd: 487.0 cm²; Re: 3.50 Ω; Le: 2.10 mH; Sensitivity: 90.6 dB; Nominal Z: 4.4 Ω; Measured range: 10-20000 Hz

Driver quality scores

On-axis flatness 55 · DI tracking 48 · DI smoothness 36

Usable passband

Scored passband 45 Hz–2.4 kHz

Measurement coverage

Measured profiles · Off-axis H/V response data available.

Recommended enclosure

Sealed ~144.3 L

Measurement profiles

uploaded measurement (measured)

Measurement quality

LoudspeakerLab evidence grade: A- (80.0/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.
