Dayton Audio PA310-8 standard | Fs 39 Hz, 96.1 dB, Qts 0.290 | LoudspeakerLab

Thiele-Small parameters

Fs: 39 Hz; Qts: 0.290; Qes: 0.300; Qms: 8.850; Vas: 91.80 L; Sd: 530.9 cm²; Re: 5.50 Ω; Le: 1.68 mH; Sensitivity: 96.1 dB; Nominal Z: 6.3 Ω; Measured range: 21-19997 Hz

Driver quality scores

On-axis flatness 28

Usable passband

Scored passband 89 Hz–2.5 kHz

Measurement coverage

Measured profiles

Recommended enclosure

Vented ~40.2 L · Fb 59 Hz

Measurement profiles

• uploaded measurement (measured)

Public designs

1 public loudspeaker design on LoudspeakerLab use this driver.

• Electro-Voice ELX-112P woofer retro-fit with Dayton Audio PA310-8

Where to buy

• solen.ca — $178.02 CAD

Measurement quality

LoudspeakerLab evidence grade: B (70.0/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Also known as

Dayton Audio PA310-8 12" Pro Woofer
