Dayton Audio NHP25Ti standard | Fs 1625 Hz, 93.8 dB, Qts 1.713 | LoudspeakerLab

Thiele-Small parameters

Fs: 1625 Hz; Qts: 1.713; Qes: 2.542; Qms: 5.250; Re: 3.23 Ω; Sensitivity: 93.8 dB; Nominal Z: 3.2 Ω; Measured range: 298-20000 Hz

Driver quality scores

On-axis flatness 73 · DI tracking 74 · DI smoothness 20

Usable passband

Scored passband 3236 Hz–8.2 kHz

Measurement coverage

Measured profiles · Off-axis H/V response data available.

Measurement profiles

• uploaded measurement (measured)

Measurement quality

LoudspeakerLab evidence grade: B+ (77.8/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Also known as

NHP25Ti Factory Data
