Dayton Audio LW150-4 standard | Fs 63 Hz, 83.0 dB, Qts 0.640 | LoudspeakerLab

Thiele-Small parameters

Fs: 63 Hz; Qts: 0.640; Qes: 0.720; Qms: 6.010; Vas: 3.49 L; Sd: 91.6 cm²; Re: 3.60 Ω; Le: 0.86 mH; Sensitivity: 83.0 dB; Nominal Z: 3.9 Ω; Measured range: 20-20000 Hz

Driver quality scores

On-axis flatness 63 · DI tracking 79 · DI smoothness 53

Usable passband

Scored passband 93 Hz–1.7 kHz

Measurement coverage

Spec-sheet profiles · Off-axis H/V response data available.

Recommended enclosure

Sealed ~6.1 L

Measurement profiles

• spec sheet (spec_sheet)

Where to buy

• blackdotaudio — $225.54 PLN
• parts_express — $54.98 USD
• solen — $86.48 CAD
• soundimports — $51.61 EUR
• theloudspeakerkit — $109.00 AUD

Measurement quality

LoudspeakerLab evidence grade: C+ (56.8/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.
