Dayton Audio E180HE-44 standard | Fs 35 Hz, 80.2 dB, Qts 0.460 | LoudspeakerLab

Thiele-Small parameters

Fs: 35 Hz; Qts: 0.460; Qes: 0.540; Qms: 2.930; Vas: 16.14 L; Sd: 136.1 cm²; Re: 6.80 Ω; Le: 1.50 mH; Sensitivity: 80.2 dB; Nominal Z: 8.8 Ω; Measured range: 15-20000 Hz

Driver quality scores

On-axis flatness 74 · DI tracking 35 · DI smoothness 33

Usable passband

Scored passband 58 Hz–4.6 kHz

Measurement coverage

Spec-sheet profiles · Off-axis H/V response data available.

Recommended enclosure

Vented ~17.6 L · Fb 34 Hz

Measurement profiles

• spec sheet (spec_sheet)

Where to buy

• blackdotaudio — $674.89 PLN
• parts_express — $139.98 USD
• soundimports — $165.25 EUR

Measurement quality

LoudspeakerLab evidence grade: C+ (56.8/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.
