Dayton Audio E150MR-8 standard | Fs 74 Hz, 89.6 dB, Qts 0.580 | LoudspeakerLab

Thiele-Small parameters

Fs: 74 Hz; Qts: 0.580; Qes: 0.670; Qms: 4.230; Vas: 8.00 L; Sd: 100.3 cm²; Re: 6.50 Ω; Le: 0.10 mH; Sensitivity: 89.6 dB; Nominal Z: 7.1 Ω; Measured range: 10-20000 Hz

Driver quality scores

On-axis flatness 52 · DI tracking 0 · DI smoothness 34

Usable passband

Scored passband 110 Hz–13.2 kHz

Measurement coverage

Spec-sheet profiles · Off-axis H/V response data available.

Recommended enclosure

Vented ~15.2 L · Fb 60 Hz

Measurement profiles

• spec sheet (spec_sheet)

Where to buy

• parts_express — $59.98 USD
• solen — $88.16 CAD
• soundimports — $74.34 EUR

Measurement quality

LoudspeakerLab evidence grade: C+ (53.8/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.
