Dayton Audio DSA270-8 standard | Fs 30 Hz, 90.4 dB, Qts 0.379 | LoudspeakerLab

Thiele-Small parameters

Fs: 30 Hz; Qts: 0.379; Qes: 0.462; Qms: 2.112; Vas: 88.10 L; Sd: 353.0 cm²; Re: 5.22 Ω; Sensitivity: 90.4 dB; Nominal Z: 5.7 Ω; Measured range: 20-20000 Hz

Driver quality scores

On-axis flatness 76 · DI tracking 64 · DI smoothness 66

Usable passband

Scored passband 45 Hz–2.8 kHz

Measurement coverage

Measured profiles · Off-axis H/V response data available.

Recommended enclosure

Vented ~63.1 L · Fb 35 Hz

Measurement profiles

• uploaded measurement (measured)

Where to buy

• blackdotaudio — $644.79 PLN

Measurement quality

LoudspeakerLab evidence grade: A (90.6/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Also known as

DSA270-8 10" Designer Series Aluminum Cone Woofer, Dayton Audio DSA270-8 10" Designer Series Aluminum Cone Woofer
