Dayton Audio DS270-8 standard | Fs 32 Hz, 90.7 dB, Qts 0.440 | LoudspeakerLab

Name: Dayton Audio DS270-8 standard | Fs 32 Hz, 90.7 dB, Qts 0.440 | LoudspeakerLab
Brand: Dayton Audio
SKU: DS270-8
Price: 528.69 PLN
Availability: InStock

Dayton Audio DS270-8 standard measurements on LoudspeakerLab. 90.7 dB sensitivity. Fs 32 Hz. Qts 0.440. Evidence grade C (44.0/100).

Thiele-Small parameters

Fs: 32 Hz; Qts: 0.440; Qes: 0.540; Qms: 2.400; Vas: 87.70 L; Sd: 353.0 cm²; Re: 5.40 Ω; Le: 1.25 mH; Sensitivity: 90.7 dB; Nominal Z: 6.1 Ω; Measured range: 20-5000 Hz

Driver quality scores

On-axis flatness 86

Usable passband

Scored passband 48 Hz–2.0 kHz

Measurement coverage

Spec-sheet profiles

Recommended enclosure

Vented ~86.3 L · Fb 32 Hz

Measurement profiles

spec sheet (spec_sheet)

Where to buy

blackdotaudio — $528.69 PLN
parts_express — $87.98 USD
rumoh — $122.90 EUR
solen — $128.11 CAD
soundimports — $101.61 EUR

Measurement quality

LoudspeakerLab evidence grade: C (44.0/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.
