Dayton Audio DMA105-4 standard | Fs 73 Hz, 87.6 dB, Qts 0.509 | LoudspeakerLab

Thiele-Small parameters

Fs: 73 Hz; Qts: 0.509; Qes: 0.631; Qms: 2.649; Vas: 4.35 L; Sd: 54.1 cm²; Re: 3.42 Ω; Le: 0.29 mH; Sensitivity: 87.6 dB; Nominal Z: 3.6 Ω; Measured range: 20-20000 Hz

Driver quality scores

On-axis flatness 76 · DI tracking 73 · DI smoothness 48

Usable passband

Scored passband 107 Hz–4.7 kHz

Measurement coverage

Spec-sheet profiles · Off-axis H/V response data available.

Recommended enclosure

Vented ~6.0 L · Fb 65 Hz

Measurement profiles

• spec sheet (spec_sheet)

Where to buy

• parts_express — $19.98 USD
• solen — $25.65 CAD
• soundimports — $26.41 EUR

Measurement quality

LoudspeakerLab evidence grade: C+ (56.8/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.
