Dayton Audio CX120-8 Tweeter standard | Fs 2745 Hz, 89.2 dB, Qts 1.722 | LoudspeakerLab

Dayton Audio CX120-8 Tweeter standard measurements on LoudspeakerLab. 89.2 dB sensitivity. Fs 2745 Hz. Qts 1.722. Evidence grade B+ (78.8/100).

Thiele-Small parameters

Fs: 2745 Hz; Qts: 1.722; Qes: 7.911; Qms: 2.202; Vas: 0.00 L; Sd: 0.0 cm²; Re: 5.58 Ω; Le: 0.19 mH; Sensitivity: 89.2 dB; Nominal Z: 5.6 Ω; Measured range: 298-20000 Hz

Driver quality scores

On-axis flatness 56 · DI tracking 0 · DI smoothness 0

Usable passband

Scored passband 2256 Hz–20.0 kHz

Measurement coverage

Measured profiles · Off-axis H/V response data available.

Measurement profiles

uploaded measurement (measured)

Measurement quality

LoudspeakerLab evidence grade: B+ (78.8/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.
