Dayton Audio CF18N-4 standard | Fs 1100 Hz, 90.0 dB, Qts 1.200 | LoudspeakerLab

Thiele-Small parameters

Fs: 1100 Hz; Qts: 1.200; Qes: 3.100; Qms: 2.000; Sd: 2.5 cm²; Re: 3.54 Ω; Le: 0.01 mH; Sensitivity: 90.0 dB; Nominal Z: 3.6 Ω; Measured range: 5-20000 Hz

Driver quality scores

On-axis flatness 61 · DI tracking 57 · DI smoothness 3 · THD 89 · Composite 57

Usable passband

Scored passband 2222 Hz–15.9 kHz

Measurement coverage

Distortion measurements · Spec-sheet profiles · Off-axis H/V response data available.

Measurement profiles

• spec sheet (spec_sheet)

Where to buy

• parts_express — $25.98 USD
• solen — $37.78 CAD
• soundimports — $30.54 EUR

Measurement quality

LoudspeakerLab evidence grade: C+ (61.6/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.
