SB Acoustics SATORI WO24P-4 standard | Fs 28 Hz, 91.0 dB, Qts 0.400 | LoudspeakerLab

Thiele-Small parameters

Fs: 28 Hz; Qts: 0.400; Qes: 0.420; Qms: 6.700; Vas: 71.00 L; Sd: 255.0 cm²; Re: 3.30 Ω; Le: 0.29 mH; Sensitivity: 91.0 dB; Nominal Z: 4.2 Ω; Measured range: 20-20000 Hz

Driver quality scores

On-axis flatness 52 · DI tracking 0 · DI smoothness 0

Usable passband

Scored passband 61 Hz–6.4 kHz

Measurement coverage

Measured profiles · Off-axis H/V response data available.

Recommended enclosure

Vented ~57.3 L · Fb 31 Hz

Measurement profiles

• uploaded measurement (measured)

Where to buy

• audiohobby — $190.00 EUR
• blackdotaudio — $1088.83 PLN
• madisound — $255.00 USD
• rumoh — $234.00 EUR
• solen — $370.05 CAD

Measurement quality

LoudspeakerLab evidence grade: A- (80.0/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Manufacturer

• SB Acoustics
