FaitalPRO 4FE32 (4 Ohm) standard | Fs 100 Hz, 92.8 dB, Qts 0.530 | LoudspeakerLab

Name: FaitalPRO 4FE32 (4 Ohm) standard | Fs 100 Hz, 92.8 dB, Qts 0.530 | LoudspeakerLab
Brand: FaitalPRO
SKU: 4FE32 (4 Ohm)
Price: 18.30 GBP
Availability: InStock

FaitalPRO 4FE32 (4 Ohm) standard measurements on LoudspeakerLab. 92.8 dB sensitivity. Fs 100 Hz. Qts 0.530. Evidence grade C+ (57.0/100).

Thiele-Small parameters

Fs: 100 Hz; Qts: 0.530; Qes: 0.620; Qms: 3.500; Vas: 2.50 L; Sd: 51.9 cm²; Re: 3.30 Ω; Le: 0.11 mH; Sensitivity: 92.8 dB; Nominal Z: 3.8 Ω; Measured range: 20-20000 Hz

Driver quality scores

On-axis flatness 54

Usable passband

Scored passband 147 Hz–7.0 kHz

Measurement coverage

Spec-sheet profiles · Off-axis H/V response data available.

Recommended enclosure

Vented ~3.8 L · Fb 87 Hz

Measurement profiles

spec sheet (spec_sheet)

Where to buy

bluearan — $18.30 GBP
parts_express — $51.25 USD
soundimports — $30.54 EUR

Measurement quality

LoudspeakerLab evidence grade: C+ (57.0/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Manufacturer

FaitalPRO
