FaitalPRO 3FE26 (16 Ohm) standard | Fs 150 Hz, 89.9 dB, Qts 1.080 | LoudspeakerLab

Name: FaitalPRO 3FE26 (16 Ohm) standard | Fs 150 Hz, 89.9 dB, Qts 1.080 | LoudspeakerLab
Brand: FaitalPRO
SKU: 3FE26 (16 Ohm)
Price: 12.52 GBP
Availability: InStock

FaitalPRO 3FE26 (16 Ohm) standard measurements on LoudspeakerLab. 89.9 dB sensitivity. Fs 150 Hz. Qts 1.080. Evidence grade C+ (57.0/100).

Thiele-Small parameters

Fs: 150 Hz; Qts: 1.080; Qes: 1.560; Qms: 3.490; Vas: 0.90 L; Sd: 33.0 cm²; Re: 12.30 Ω; Le: 0.18 mH; Sensitivity: 89.9 dB; Nominal Z: 13.1 Ω; Measured range: 20-20000 Hz

Driver quality scores

On-axis flatness 62

Usable passband

Scored passband 227 Hz–8.5 kHz

Measurement coverage

Spec-sheet profiles · Off-axis H/V response data available.

Recommended enclosure

Sealed ~2.2 L

Measurement profiles

spec sheet (spec_sheet)

Where to buy

bluearan — $12.52 GBP

Measurement quality

LoudspeakerLab evidence grade: C+ (57.0/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Manufacturer

FaitalPRO
