FaitalPRO 12FE330 standard | Fs 33 Hz, 93.8 dB, Qts 0.450 | LoudspeakerLab

FaitalPRO 12FE330 standard measurements on LoudspeakerLab. 93.8 dB sensitivity. Fs 33 Hz. Qts 0.450. Evidence grade C (47.0/100).

Preview

Thiele-Small parameters

Fs: 33 Hz; Qts: 0.450; Qes: 0.480; Qms: 7.000; Vas: 5.18 L; Sd: 579.0 cm²; Re: 5.30 Ω; Le: 1.10 mH; Sensitivity: 93.8 dB; Nominal Z: 5.9 Ω; Measured range: 10-20000 Hz

Driver quality scores

On-axis flatness 65

Usable passband

Scored passband 31 Hz–1.5 kHz

Measurement coverage

Spec-sheet profiles

Recommended enclosure

Vented ~5.4 L · Fb 33 Hz

Measurement profiles

Where to buy

Measurement quality

LoudspeakerLab evidence grade: C (47.0/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.
