Accuton C51-6 standard | Fs 581 Hz, 93.5 dB, Qts 1.210 | LoudspeakerLab

Thiele-Small parameters

Fs: 581 Hz; Qts: 1.210; Qes: 1.610; Qms: 4.860; Sd: 24.0 cm²; Re: 5.60 Ω; Sensitivity: 93.5 dB; Nominal Z: 6.3 Ω; Measured range: 101-19628 Hz

Driver quality scores

On-axis flatness 76 · THD 94

Usable passband

Scored passband 1177 Hz–8.6 kHz

Measurement coverage

Distortion measurements · Spec-sheet profiles

Measurement profiles

• spec sheet (spec_sheet)

Where to buy

• soundimports — $561.94 EUR

Measurement quality

LoudspeakerLab evidence grade: C+ (52.2/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Also known as

C51-6-286
