PT103 - LoudspeakerLab Design

Design summary

Preference rating 7.2 · F3 34 Hz · Max SPL 97 dB at 1 kHz · Min impedance 3.5 Ω · Sensitivity 82.8 dB · Estimated cost USD 2207

Drivers

• Purifi PTT1.3T04-HAG-01 (tweeter)
• Purifi PTT10.0X04-NAB-01 (woofer)
• Purifi PTT6.5X08-NAA-08 (midrange)

Enclosure

Baffle 332 × 728 mm
