Wavecor WF223BD02 standard | Fs 33 Hz, 86.5 dB, Qts 0.460 | LoudspeakerLab

Thiele-Small parameters

Fs: 33 Hz; Qts: 0.460; Qes: 0.470; Qms: 14.300; Vas: 45.02 L; Sd: 213.0 cm²; Re: 6.20 Ω; Le: 0.20 mH; Sensitivity: 86.5 dB; Nominal Z: 7.1 Ω; Measured range: 20-20000 Hz

Driver quality scores

On-axis flatness 55 · DI tracking 39 · DI smoothness 80

Usable passband

Scored passband 54 Hz–3.6 kHz

Measurement coverage

Measured profiles · Off-axis H/V response data available.

Recommended enclosure

Vented ~49.0 L · Fb 32 Hz

Measurement profiles

• uploaded measurement (measured)

Where to buy

• rumoh.eu — $245.00 EUR

Measurement quality

LoudspeakerLab evidence grade: A- (80.0/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Also known as

Wavecor WF223BD02
