Wavecor WF166TU02 standard | Fs 50 Hz, 90.7 dB, Qts 0.480 | LoudspeakerLab

Thiele-Small parameters

Fs: 50 Hz; Qts: 0.480; Qes: 0.500; Qms: 9.800; Vas: 22.37 L; Sd: 139.0 cm²; Re: 3.20 Ω; Le: 0.23 mH; Sensitivity: 90.7 dB; Nominal Z: 3.4 Ω; Measured range: 20-20000 Hz

Driver quality scores

On-axis flatness 74

Usable passband

Scored passband 76 Hz–8.9 kHz

Measurement coverage

Spec-sheet profiles

Recommended enclosure

Vented ~26.8 L · Fb 47 Hz

Measurement profiles

• spec sheet (spec_sheet)

Where to buy

• parts_express — $129.00 USD

Measurement quality

LoudspeakerLab evidence grade: C (46.8/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Manufacturer

• Wavecor
