Wavecor WF118WA02 standard | Fs 65 Hz, 86.0 dB, Qts 0.440 | LoudspeakerLab

Thiele-Small parameters

Fs: 65 Hz; Qts: 0.440; Qes: 0.460; Qms: 8.800; Vas: 4.25 L; Sd: 55.0 cm²; Re: 6.30 Ω; Le: 0.28 mH; Sensitivity: 86.0 dB; Nominal Z: 6.9 Ω; Measured range: 20-20000 Hz

Driver quality scores

On-axis flatness 52

Usable passband

Scored passband 90 Hz–12.1 kHz

Measurement coverage

Spec-sheet profiles

Recommended enclosure

Vented ~4.2 L · Fb 66 Hz

Measurement profiles

• spec sheet (spec_sheet)

Where to buy

• parts_express — $70.00 USD
• rumoh — $89.50 EUR

Measurement quality

LoudspeakerLab evidence grade: C (46.8/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Manufacturer

• Wavecor
