Thiele-Small parameters

Fs: 425 Hz; Qts: 0.900; Qes: 1.740; Qms: 1.900; Re: 6.50 Ω; Le: 35.00 mH; Sensitivity: 91.3 dB; Nominal Z: 6.8 Ω; Measured range: 200-40000 Hz

Driver quality scores

On-axis flatness 84

Usable passband

Scored passband 588 Hz–20.0 kHz

Measurement coverage

Spec-sheet profiles

Measurement profiles

• spec sheet (spec_sheet)

Where to buy

• parts_express — $87.00 USD
• rumoh — $132.00 EUR
• solen — $120.99 CAD

Measurement quality

LoudspeakerLab evidence grade: C (45.2/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Manufacturer

• Wavecor
