Wavecor TW030WA05 standard | Fs 445 Hz, 91.5 dB, Qts 0.777 | LoudspeakerLab

Thiele-Small parameters

Fs: 445 Hz; Qts: 0.777; Qes: 1.277; Qms: 1.983; Re: 3.69 Ω; Sensitivity: 91.5 dB; Nominal Z: 3.7 Ω; Measured range: 100-40000 Hz

Driver quality scores

On-axis flatness 68

Usable passband

Scored passband 1004 Hz–20.0 kHz

Measurement coverage

Spec-sheet profiles

Measurement profiles

• spec sheet (spec_sheet)

Where to buy

• audiohobby — $70.80 EUR
• cinergyaudio — $36.00 USD
• rumoh — $112.00 EUR
• solen — $107.18 CAD

Measurement quality

LoudspeakerLab evidence grade: C (45.0/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Manufacturer

• Wavecor
