Wavecor SW215WA01 standard | Fs 33 Hz, 86.1 dB, Qts 0.490 | LoudspeakerLab

Thiele-Small parameters

Fs: 33 Hz; Qts: 0.490; Qes: 0.510; Qms: 11.000; Vas: 26.05 L; Sd: 206.0 cm²; Re: 3.30 Ω; Le: 1.20 mH; Sensitivity: 86.1 dB; Nominal Z: 3.9 Ω; Measured range: 20-20000 Hz

Driver quality scores

On-axis flatness 48

Usable passband

Scored passband 48 Hz–1.0 kHz

Measurement coverage

Spec-sheet profiles

Recommended enclosure

Vented ~32.9 L · Fb 30 Hz

Measurement profiles

• spec sheet (spec_sheet)

Where to buy

• parts_express — $128.00 USD
• rumoh — $172.00 EUR

Measurement quality

LoudspeakerLab evidence grade: C (46.8/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Manufacturer

• Wavecor
