Visaton G 20 SC standard | Fs 1890 Hz, 88.0 dB, Qts 0.280 | LoudspeakerLab

Thiele-Small parameters

Fs: 1890 Hz; Qts: 0.280; Qes: 1.340; Qms: 0.360; Sd: 4.0 cm²; Re: 8.00 Ω; Le: 0.02 mH; Sensitivity: 88.0 dB; Nominal Z: 5.2 Ω; Measured range: 20-19897 Hz

Driver quality scores

On-axis flatness 71 · DI tracking 70 · DI smoothness 78

Usable passband

Scored passband 1666 Hz–20.0 kHz

Measurement coverage

Measured profiles · Off-axis H/V response data available.

Measurement profiles

• uploaded measurement (measured)

Where to buy

• digikey — $56.90 USD

Measurement quality

LoudspeakerLab evidence grade: B+ (78.6/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Also known as

Visaton G 20 SC

Manufacturer

• Visaton
