SILVER FLUTE W14RC2508 standard | Fs 44 Hz, 87.5 dB, Qts 0.350 | LoudspeakerLab

SILVER FLUTE W14RC2508 standard measurements on LoudspeakerLab. 87.5 dB sensitivity. Fs 44 Hz. Qts 0.350. Evidence grade B (69.8/100).

Preview

Thiele-Small parameters

Fs: 44 Hz; Qts: 0.350; Qes: 0.390; Qms: 3.270; Vas: 18.90 L; Sd: 0.0 cm²; Re: 7.30 Ω; Le: 0.77 mH; Sensitivity: 87.5 dB; Nominal Z: 8.0 Ω; Measured range: 20-20000 Hz

Driver quality scores

On-axis flatness 46

Usable passband

Scored passband 4386 Hz–11.2 kHz

Measurement coverage

Measured profiles

Recommended enclosure

Vented ~11.7 L · Fb 55 Hz

Measurement profiles

Measurement quality

LoudspeakerLab evidence grade: B (69.8/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.
