SEAS T35C002 standard | Fs 620 Hz, 95.0 dB, Qts 0.465 | LoudspeakerLab

Thiele-Small parameters

Fs: 620 Hz; Qts: 0.465; Qes: 0.767; Qms: 1.182; Sd: 11.9 cm²; Re: 4.60 Ω; Le: 0.06 mH; Sensitivity: 95.0 dB; Nominal Z: 6.0 Ω; Measured range: 105-20000 Hz

Driver quality scores

On-axis flatness 73

Usable passband

Scored passband 1096 Hz–19.4 kHz

Measurement coverage

Spec-sheet profiles

Measurement profiles

• spec sheet (spec_sheet)

Where to buy

• audioxcel — $360.95 EUR
• hificollective — $276.27 GBP
• madisound — $362.20 USD
• rumoh — $379.00 EUR
• solen — $552.48 CAD

Measurement quality

LoudspeakerLab evidence grade: C (46.2/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Manufacturer

• SEAS
