SEAS T25CF001 standard | Fs 700 Hz, 91.0 dB, Qts 0.446 | LoudspeakerLab

Thiele-Small parameters

Fs: 700 Hz; Qts: 0.446; Qes: 0.866; Qms: 0.922; Sd: 7.0 cm²; Re: 4.60 Ω; Le: 0.05 mH; Sensitivity: 91.0 dB; Nominal Z: 6.0 Ω; Measured range: 100-19848 Hz

Driver quality scores

On-axis flatness 80 · DI tracking 25 · DI smoothness 24

Usable passband

Scored passband 1526 Hz–12.4 kHz

Measurement coverage

Spec-sheet profiles · Off-axis H/V response data available.

Measurement profiles

• spec sheet (spec_sheet)

Where to buy

• audioxcel — $189.95 EUR
• madisound — $197.60 USD
• rumoh — $199.00 EUR
• solen — $295.79 CAD
• soundimports — $165.25 EUR

Measurement quality

LoudspeakerLab evidence grade: C+ (56.2/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Manufacturer

• SEAS
