SB Acoustics SB42FHCL75-6 standard | Fs 18 Hz, 94.0 dB, Qts 0.310 | LoudspeakerLab

Thiele-Small parameters

Fs: 18 Hz; Qts: 0.310; Qes: 0.320; Qms: 7.400; Vas: 462.00 L; Sd: 850.0 cm²; Re: 4.60 Ω; Le: 2.10 mH; Sensitivity: 94.0 dB; Nominal Z: 6.1 Ω; Measured range: 10-20000 Hz

Driver quality scores

On-axis flatness 68 · DI tracking 58 · DI smoothness 42

Usable passband

Scored passband 28 Hz–1.6 kHz

Measurement coverage

Spec-sheet profiles · Off-axis H/V response data available.

Recommended enclosure

Vented ~226.9 L · Fb 26 Hz

Measurement profiles

• spec sheet (spec_sheet)

Where to buy

• madisound — $499.00 USD
• solen — $626.04 CAD
• soundimports — $396.65 EUR
• theloudspeakerkit — $799.00 AUD

Measurement quality

LoudspeakerLab evidence grade: C+ (57.0/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Also known as

SB42FHCL75-6 - Spec Sheet

Manufacturer

• SB Acoustics
