SB Acoustics SB29BNC-C000 standard | Fs 950 Hz, 95.0 dB, Qts 0.690 | LoudspeakerLab

Thiele-Small parameters

Fs: 950 Hz; Qts: 0.690; Qes: 1.400; Qms: 1.360; Sd: 9.6 cm²; Re: 3.00 Ω; Le: 0.05 mH; Sensitivity: 95.0 dB; Nominal Z: 4.0 Ω; Measured range: 103-20000 Hz

Driver quality scores

On-axis flatness 78 · DI tracking 72 · DI smoothness 50

Usable passband

Scored passband 1868 Hz–15.6 kHz

Measurement coverage

Spec-sheet profiles · Off-axis H/V response data available.

Measurement profiles

• IEC baffle (spec_sheet)

Where to buy

• madisound — $325.40 USD
• solen — $732.78 CAD
• soundimports — $235.50 EUR

Measurement quality

LoudspeakerLab evidence grade: C+ (56.2/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Also known as

SB29BNC-C000-4

Manufacturer

• SB Acoustics
