SB Acoustics SB26STCN-C000 standard | Fs 960 Hz, 92.4 dB, Qts 0.840 | LoudspeakerLab

Thiele-Small parameters

Fs: 960 Hz; Qts: 0.840; Qes: 1.770; Qms: 1.600; Sd: 6.2 cm²; Re: 3.20 Ω; Le: 0.04 mH; Sensitivity: 92.4 dB; Nominal Z: 4.0 Ω; Measured range: 5-39794 Hz

Driver quality scores

On-axis flatness 87

Usable passband

Scored passband 1004 Hz–20.0 kHz

Measurement coverage

Spec-sheet profiles

Measurement profiles

• IEC baffle (spec_sheet)

Where to buy

• madisound — $40.50 USD
• solen — $49.82 CAD
• soundimports — $30.12 EUR
• theloudspeakerkit — $55.00 AUD

Measurement quality

LoudspeakerLab evidence grade: C (46.0/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Also known as

SB26STCN-C000-4
