Peerless XT25BG60-04 standard | Fs 589 Hz, 92.3 dB, Qts 0.320 | LoudspeakerLab

Thiele-Small parameters

Fs: 589 Hz; Qts: 0.320; Qes: 0.430; Qms: 1.310; Vas: 0.02 L; Sd: 8.2 cm²; Re: 3.00 Ω; Le: 0.01 mH; Sensitivity: 92.3 dB; Nominal Z: 3.4 Ω; Measured range: 20-19999 Hz

Driver quality scores

On-axis flatness 72

Usable passband

Scored passband 1004 Hz–20.0 kHz

Measurement coverage

Measured profiles

Recommended enclosure

Vented ~0.0 L · Fb 809 Hz

Measurement profiles

• uploaded measurement (measured)

Where to buy

• blackdotaudio — $214.79 PLN
• parts_express — $41.98 USD
• soundimports — $41.28 EUR

Measurement quality

LoudspeakerLab evidence grade: B (69.8/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.
