Peerless P830983 standard | Fs 140 Hz, 84.6 dB, Qts 0.630 | LoudspeakerLab

Thiele-Small parameters

Fs: 140 Hz; Qts: 0.630; Qes: 0.697; Qms: 6.530; Vas: 0.24 L; Sd: 15.2 cm²; Re: 3.40 Ω; Le: 0.03 mH; Sensitivity: 84.6 dB; Nominal Z: 3.6 Ω; Measured range: 20-40000 Hz

Driver quality scores

On-axis flatness 46 · DI tracking 0 · DI smoothness 0

Usable passband

Scored passband 1004 Hz–20.0 kHz

Measurement coverage

Spec-sheet profiles · Off-axis H/V response data available.

Recommended enclosure

Sealed ~0.4 L

Measurement profiles

• spec sheet (spec_sheet)

Where to buy

• parts_express — $33.29 USD
• soundimports — $22.27 EUR

Measurement quality

LoudspeakerLab evidence grade: C+ (56.8/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Also known as

PLS-P830983

Manufacturer

• Peerless
