Peerless FSL-0512R01 standard | Fs 120 Hz, 91.3 dB, Qts 0.580 | LoudspeakerLab

Thiele-Small parameters

Fs: 120 Hz; Qts: 0.580; Qes: 0.760; Qms: 2.410; Vas: 3.48 L; Sd: 100.0 cm²; Re: 5.90 Ω; Le: 0.28 mH; Sensitivity: 91.3 dB; Nominal Z: 6.5 Ω; Measured range: 20-20000 Hz

Driver quality scores

On-axis flatness 52 · DI tracking 0 · DI smoothness 0

Usable passband

Scored passband 160 Hz–12.2 kHz

Measurement coverage

Spec-sheet profiles · Off-axis H/V response data available.

Recommended enclosure

Vented ~6.6 L · Fb 97 Hz

Measurement profiles

• spec sheet (spec_sheet)

Where to buy

• soundimports — $20.62 EUR

Measurement quality

LoudspeakerLab evidence grade: C+ (56.8/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Also known as

FSL-0512R01-08

Manufacturer

• Peerless
