Peerless BC25SC06-04 standard | Fs 1395 Hz, 96.2 dB, Qts 1.170 | LoudspeakerLab

Thiele-Small parameters

Fs: 1395 Hz; Qts: 1.170; Qes: 1.760; Qms: 3.450; Vas: 0.00 L; Re: 2.76 Ω; Le: 0.02 mH; Sensitivity: 96.2 dB; Nominal Z: 3.3 Ω; Measured range: 10-20000 Hz

Driver quality scores

On-axis flatness 66

Usable passband

Scored passband 2720 Hz–20.0 kHz

Measurement coverage

Measured profiles

Measurement profiles

• uploaded measurement (measured)

Where to buy

• blackdotaudio — $107.29 PLN
• parts_express — $15.69 USD
• soundimports — $24.95 EUR

Measurement quality

LoudspeakerLab evidence grade: B (69.6/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.
