Morel CAT 378 standard | Fs 698 Hz, 93.3 dB, Qts 0.588 | LoudspeakerLab

Thiele-Small parameters

Fs: 698 Hz; Qts: 0.588; Qes: 0.977; Qms: 1.476; Vas: 0.00 L; Sd: 6.0 cm²; Re: 5.61 Ω; Sensitivity: 93.3 dB; Nominal Z: 5.9 Ω; Measured range: 10-20000 Hz

Driver quality scores

On-axis flatness 78 · DI tracking 74 · DI smoothness 54

Usable passband

Scored passband 1666 Hz–15.0 kHz

Measurement coverage

Spec-sheet profiles · Off-axis H/V response data available.

Measurement profiles

• IEC baffle (spec_sheet)

Where to buy

• audioxcel — $94.95 EUR
• rumoh — $99.00 EUR

Measurement quality

LoudspeakerLab evidence grade: C+ (55.6/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Also known as

MOREL CAT 378
