Monacor Size105x105mm standard | Fs 65 Hz, 90.0 dB, Qts 0.490 | LoudspeakerLab

Thiele-Small parameters

Fs: 65 Hz; Qts: 0.490; Qes: 0.640; Qms: 2.100; Vas: 6.00 L; Sd: 55.0 cm²; Re: 6.50 Ω; Le: 0.30 mH; Sensitivity: 90.0 dB; Nominal Z: 7.8 Ω; Measured range: 20-20000 Hz

Driver quality scores

On-axis flatness 66

Usable passband

Scored passband 120 Hz–12.2 kHz

Measurement coverage

Measured profiles

Recommended enclosure

Vented ~7.6 L · Fb 60 Hz

Measurement profiles

• uploaded measurement (measured)

Where to buy

• wilmslowaudio.co.uk — $22.80 GBP

Measurement quality

LoudspeakerLab evidence grade: B (69.6/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Also known as

SP-60/8 Size105x105mm
