Monacor DT-284 standard | Fs 1300 Hz, 92.3 dB, Qts 0.780 | LoudspeakerLab

Name: Monacor DT-284 standard | Fs 1300 Hz, 92.3 dB, Qts 0.780 | LoudspeakerLab
Brand: Monacor
SKU: DT-284
Price: 54.00 GBP
Availability: InStock

Monacor DT-284 standard measurements on LoudspeakerLab. 92.3 dB sensitivity. Fs 1300 Hz. Qts 0.780. Evidence grade C+ (54.8/100).

Thiele-Small parameters

Fs: 1300 Hz; Qts: 0.780; Qes: 2.439; Qms: 1.147; Re: 4.14 Ω; Sensitivity: 92.3 dB; Nominal Z: 4.2 Ω; Measured range: 1089-20087 Hz

Driver quality scores

On-axis flatness 66 · DI tracking 71 · DI smoothness 58

Usable passband

Scored passband 1004 Hz–20.0 kHz

Measurement coverage

Spec-sheet profiles · Off-axis H/V response data available.

Measurement profiles

spec sheet (spec_sheet)

Where to buy

wilmslow — $54.00 GBP

Measurement quality

LoudspeakerLab evidence grade: C+ (54.8/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.
