Markaudio CHN 50 standard | Fs 72 Hz, 85.7 dB, Qts 0.611 | LoudspeakerLab

Markaudio CHN 50 standard measurements on LoudspeakerLab. 85.7 dB sensitivity. Fs 72 Hz. Qts 0.611. Also known as Markaudio CHN 50. Evidence grade B...

Preview

Thiele-Small parameters

Fs: 72 Hz; Qts: 0.611; Qes: 0.791; Qms: 2.688; Vas: 1.10 L; Sd: 0.0 cm²; Re: 6.51 Ω; Sensitivity: 85.7 dB; Nominal Z: 6.0 Ω; Measured range: 20-20000 Hz

Driver quality scores

On-axis flatness 62

Usable passband

Scored passband 3688 Hz–20.0 kHz

Measurement coverage

Measured profiles

Recommended enclosure

Sealed ~2.1 L

Measurement profiles

Measurement quality

LoudspeakerLab evidence grade: B (68.6/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Also known as

Markaudio CHN 50
