Lii Audio Fast 8 standard | Fs 47 Hz, 94.0 dB, Qts 0.620 | LoudspeakerLab

Thiele-Small parameters

Fs: 47 Hz; Qts: 0.620; Qes: 64.660; Qms: 7.100; Vas: 69.70 L; Sd: 213.0 cm²; Re: 6.33 Ω; Le: 0.68 mH; Sensitivity: 94.0 dB; Nominal Z: 7.0 Ω; Measured range: 20-20000 Hz

Driver quality scores

On-axis flatness 56

Usable passband

Scored passband 67 Hz–15.2 kHz

Measurement coverage

Measured profiles

Recommended enclosure

Sealed ~127.2 L

Measurement profiles

• uploaded measurement (measured)

Measurement quality

LoudspeakerLab evidence grade: B (69.6/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.
