HiVi M5N standard | Fs 50 Hz, 87.0 dB, Qts 0.350 | LoudspeakerLab

Thiele-Small parameters

Fs: 50 Hz; Qts: 0.350; Qes: 0.370; Qms: 6.510; Vas: 11.33 L; Sd: 87.0 cm²; Re: 6.50 Ω; Sensitivity: 87.0 dB; Nominal Z: 6.6 Ω; Measured range: 10-20000 Hz

Driver quality scores

On-axis flatness 54

Usable passband

Scored passband 85 Hz–3.8 kHz

Measurement coverage

Measured profiles · Off-axis H/V response data available.

Recommended enclosure

Vented ~7.0 L · Fb 63 Hz

Measurement profiles

• uploaded measurement (measured)

Measurement quality

LoudspeakerLab evidence grade: B+ (79.6/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.
