HiVi DM-7600 standard | Fs 298 Hz, 90.3 dB, Qts 0.732 | LoudspeakerLab

HiVi DM-7600 standard measurements on LoudspeakerLab. 90.3 dB sensitivity. Fs 298 Hz. Qts 0.732. Evidence grade C (44.8/100).

Preview

Thiele-Small parameters

Fs: 298 Hz; Qts: 0.732; Qes: 1.075; Qms: 2.289; Re: 4.07 Ω; Sensitivity: 90.3 dB; Nominal Z: 4.7 Ω; Measured range: 10-20000 Hz

Driver quality scores

On-axis flatness 84

Usable passband

Scored passband 588 Hz–8.5 kHz

Measurement coverage

Spec-sheet profiles

Measurement profiles

Measurement quality

LoudspeakerLab evidence grade: C (44.8/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.
