GRS 6SMP-4 standard | Fs 46 Hz, 89.3 dB, Qts 0.386 | LoudspeakerLab

Name: GRS 6SMP-4 standard | Fs 46 Hz, 89.3 dB, Qts 0.386 | LoudspeakerLab
Brand: GRS
SKU: 6SMP-4
Price: 27.99 USD
Availability: InStock

GRS 6SMP-4 standard measurements on LoudspeakerLab. 89.3 dB sensitivity. Fs 46 Hz. Qts 0.386. Evidence grade C+ (56.8/100).

Thiele-Small parameters

Fs: 46 Hz; Qts: 0.386; Qes: 0.449; Qms: 2.734; Vas: 14.96 L; Sd: 136.8 cm²; Re: 3.66 Ω; Le: 0.29 mH; Sensitivity: 89.3 dB; Nominal Z: 4.3 Ω; Measured range: 10-20000 Hz

Driver quality scores

On-axis flatness 58 · DI tracking 62 · DI smoothness 31

Usable passband

Scored passband 69 Hz–3.6 kHz

Measurement coverage

Spec-sheet profiles · Off-axis H/V response data available.

Recommended enclosure

Vented ~11.1 L · Fb 53 Hz

Measurement profiles

spec sheet (spec_sheet)

Where to buy

parts_express — $27.99 USD
solen — $36.46 CAD
soundimports — $33.02 EUR

Measurement quality

LoudspeakerLab evidence grade: C+ (56.8/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.
