Goldwood GW-8PC-30-4 standard | Fs 44 Hz, 90.9 dB, Qts 0.450 | LoudspeakerLab

Goldwood GW-8PC-30-4 standard measurements on LoudspeakerLab. 90.9 dB sensitivity. Fs 44 Hz. Qts 0.450. Evidence grade C (44.0/100).

Preview

Thiele-Small parameters

Fs: 44 Hz; Qts: 0.450; Qes: 0.490; Qms: 5.980; Vas: 21.24 L; Sd: 205.9 cm²; Re: 3.70 Ω; Le: 1.20 mH; Sensitivity: 90.9 dB; Nominal Z: 43.0 Ω; Measured range: 19-20000 Hz

Driver quality scores

On-axis flatness 58

Usable passband

Scored passband 62 Hz–2.7 kHz

Measurement coverage

Measured profiles

Recommended enclosure

Vented ~22.1 L · Fb 44 Hz

Measurement profiles

Where to buy

Measurement quality

LoudspeakerLab evidence grade: C (44.0/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Manufacturer
