Eimsoah 30w6 standard | Fs 1791 Hz, Qts 1.889 | LoudspeakerLab

Eimsoah 30w6 standard measurements on LoudspeakerLab. Fs 1791 Hz. Qts 1.889. Also known as silkdometweeter. Evidence grade B (68.0/100).

Preview

Thiele-Small parameters

Fs: 1791 Hz; Qts: 1.889; Qes: 4.270; Qms: 3.386; Re: 5.22 Ω; Le: 0.02 mH; Nominal Z: 5.3 Ω; Measured range: 10-20000 Hz

Driver quality scores

On-axis flatness 81

Usable passband

Scored passband 3236 Hz–10.6 kHz

Measurement coverage

Measured profiles

Measurement profiles

Measurement quality

LoudspeakerLab evidence grade: B (68.0/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Also known as

silkdometweeter
