Denovo Audio Anarchy 704 standard | Fs 47 Hz, 88.1 dB, Qts 0.520 | LoudspeakerLab

Thiele-Small parameters

Fs: 47 Hz; Qts: 0.520; Qes: 0.560; Qms: 6.850; Vas: 9.61 L; Sd: 131.0 cm²; Re: 3.80 Ω; Le: 0.42 mH; Sensitivity: 88.1 dB; Nominal Z: 4.5 Ω; Measured range: 50-20000 Hz

Driver quality scores

On-axis flatness 57

Usable passband

Scored passband 82 Hz–3.4 kHz

Measurement coverage

Measured profiles

Recommended enclosure

Vented ~13.8 L · Fb 42 Hz

Measurement profiles

• uploaded measurement (measured)

Measurement quality

LoudspeakerLab evidence grade: B (69.6/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.
