Bose 111791-k standard | Fs 63 Hz, 86.9 dB, Qts 0.300 | LoudspeakerLab

Thiele-Small parameters

Fs: 63 Hz; Qts: 0.300; Qes: 0.352; Qms: 2.024; Vas: 5.02 L; Sd: 94.2 cm²; Re: 3.61 Ω; Sensitivity: 86.9 dB; Nominal Z: 4.4 Ω; Measured range: 10-20000 Hz

Driver quality scores

On-axis flatness 52

Usable passband

Scored passband 93 Hz–670 Hz

Measurement coverage

Measured profiles

Recommended enclosure

Vented ~2.3 L · Fb 92 Hz

Measurement profiles

• in-cabinet (measured)

Measurement quality

LoudspeakerLab evidence grade: C+ (60.6/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Also known as

Bose Acoustimass 600 Dual Coil Woofer

More from Bose

• 111791P
