BlieSMa T34B-4 tweeter | Fs 800 Hz, 97.0 dB, Qts 0.350 | LoudspeakerLab

Thiele-Small parameters

Fs: 800 Hz; Qts: 0.350; Qes: 0.420; Qms: 2.100; Sd: 10.5 cm²; Re: 3.30 Ω; Le: 0.01 mH; Sensitivity: 97.0 dB; Nominal Z: 3.0 Ω; Measured range: 100-20000 Hz

Driver quality scores

On-axis flatness 79 · DI tracking 62 · DI smoothness 46

Usable passband

Scored passband 1571 Hz–14.8 kHz

Measurement coverage

Spec-sheet profiles · Off-axis H/V response data available.

Measurement profiles

• IEC baffle (spec_sheet)

Where to buy

• audiohobby — $420.00 EUR
• loudspeakershop — $2390.00 PLN
• solen — $802.90 CAD
• soundimports — $661.12 EUR

Measurement quality

LoudspeakerLab evidence grade: C+ (55.8/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.
